Project Description
Parameter
Voltage class: 12V
Capacity range: 70Ah~200Ah
For high temperature applications
Long design life
Low self-discharge rate
Good high rate discharge performance
Wide operation temperature range
Technical Features
HT series is a High-temperature series sealed lead acid battery with 15 years design life in float service. It meets with IEC, JIS and BS standards .With up-dated AGM valve regulated technology and high purity raw materials, the HT series battery maintains high consistency for better performance and reliable standby service life. It is designed for using under high temperature conditions.
Application
Telecom systems, fire & alarm systems, emergency systems, power tools, medical equipment, UPS/EPS, solar inverters/controllers
Design Features
Special anti-corrosion alloy
Special anti-high-temperature paste formula
Special anti-high-temperature container
Special double sealing and anti-high-temperature sealing agent
High performance separator
Special electrolyte formula
Certificate
Specifications
| Model | Voltage（V) | Capacity(Ah) | Weight（Kg） | Dimension（mm) | Terminal type | ||||||||
| Length | Width | Height | Total Height | ||||||||||
| KG | LBS | mm | inch | mm | inch | mm | inch | mm | inch | ||||
| HT12-50L | 12 | 50 | 19 | 41.9 | 325 | 12.8 | 167 | 6.6 | 174 | 6.9 | 174 | 6.9 | T6(M6) |
| HT12-65L | 12 | 65 | 22.3 | 49.2 | 260 | 10.2 | 168 | 6.6 | 208 | 8.2 | 214 | 8.4 | T6(M6) |
| HT12-70R | 12 | 70 | 23.5 | 51.81 | 260 | 10.24 | 169 | 6.65 | 211 | 8.31 | 216 | 8.5 | F15(M6) / F11(M6) |
| HT12-80R | 12 | 80 | 30.5 | 67.24 | 306.5 | 12.07 | 168.5 | 6.63 | 210 | 8.27 | 215 | 8.46 | F15(M6) / F12(M8) |
| HT12-90R | 12 | 90 | 31 | 68.34 | 328 | 12.91 | 172 | 6.77 | 215 | 8.46 | 220 | 8.66 | F5(M8) / F12(M8) |
| HT12-100R | 12 | 100 | 34 | 74.96 | 407 | 16.02 | 177 | 6.97 | 225 | 8.86 | 225 | 8.86 | F5(M8) / F12(M8) |
| HT12-110R | 12 | 110 | 35.5 | 78.26 | 407 | 16.02 | 177 | 6.97 | 225 | 8.86 | 225 | 8.86 | F5(M8) / F12(M8) |
| HT12-130R | 12 | 130 | 43 | 94.8 | 483 | 19.02 | 170 | 6.69 | 241 | 9.49 | 241 | 9.49 | F5(M8) / F12(M8) |
| HT12-150L | 12 | 150 | 56 | 123.5 | 532 | 20.9 | 207 | 8.1 | 214 | 8.4 | 220 | 8.7 | T11(M8) |
| HT12-160R | 12 | 160 | 52 | 114.64 | 532 | 20.94 | 207 | 8.15 | 214 | 8.43 | 219 | 8.62 | F16(M8) / F12(M8) |
| HT12-200R | 12 | 200 | 63 | 138.89 | 522 | 20.55 | 240 | 9.45 | 219 | 8.62 | 224 | 8.82 | F16(M8) / F10(M8) |
| HT2-200L | 2 | 200 | 15.1 | 33.3 | 170 | 6.7 | 110 | 4.3 | 328 | 12.9 | 350 | 13.8 | T11(M8) |
| HT2-300L | 2 | 300 | 20.6 | 45.4 | 170 | 6.7 | 150 | 5.9 | 330 | 13 | 350 | 13.8 | T11(M8) |
| HT2-400L | 2 | 400 | 29.2 | 64.4 | 210 | 8.3 | 175 | 6.9 | 330 | 13 | 350 | 13.8 | T11(M8) |
| HT2-500L | 2 | 500 | 34.6 | 76.3 | 240 | 9.4 | 175 | 6.9 | 327.5 | 12.9 | 347.5 | 13.7 | T11(M8) |
| HT2-600L | 2 | 600 | 42.3 | 93.3 | 300 | 11.8 | 175 | 6.9 | 330 | 13 | 350 | 13.8 | T11(M8) |
| HT2-800L | 2 | 800 | 58.4 | 128.7 | 410 | 16.1 | 175 | 6.9 | 330 | 13 | 350 | 13.8 | T11(M8) |
| HT2-1000L | 2 | 1000 | 68 | 149.9 | 475 | 18.7 | 175 | 6.9 | 328 | 12.9 | 350 | 13.8 | T11(M8) |
| HT2-1500L | 2 | 1500 | 109.5 | 241.4 | 403 | 15.9 | 354 | 13.9 | 339 | 13.3 | 349 | 13.7 | T11(M8) |
| HT2-2000L | 2 | 2000 | 138.2 | 304.7 | 490 | 19.3 | 350 | 13.8 | 339 | 13.3 | 349 | 13.7 | T11(M8) |
| HT2-3000L | 2 | 3000 | 206.4 | 455 | 709 | 27.9 | 350 | 13.8 | 337 | 13.3 | 347 | 13.7 | T11(M8) |
